Latest Certificates
The certificate covers the WinKlik FibreCrete Window frames in conjunction with aluminium sashes and glazing for use in buildings of all occupancy classes (SANS 10400: Table 1 of regulation A (20) (1)) in all areas of South Africa.
The WinKlik FibreCrete Windows comprise a combination of fibre cement frames (mullions and transoms), aluminium sashes with monolithic or laminated glazing and ancillary components, viz, lugs, bolts, nuts and screws
The House-In-A-Can Building System is a combination of innovative and conventional construction methods. It is a single storey structure that comprises:
- foundations: cast in-situ concrete surface bed and thickened edge beams which in all cases are designed by a professional engineer or competent person.
- columns: 125 mm x 75 mm x 3 mm rectangular galvanised steel hollow sections at 2565 mm centres.
- 100 mm thick lightweight interlocking sandwich in-fill panels comprising a polystyrene beaded concrete core with a density of 650 kg m-3, encapsulated in two layers of 4,5 mm thick magnesium oxide sheets.
- light gauge structural steel roof trusses with.
- light or heavyweight roof cladding and
- insulated ceilings
- Windows are “clisco” type frames and doors frames are out of galvanised pressed steel.
- services are conventional
The MG SIP Building System is a combination of innovative and conventional construction method. It is a single storey structure that utilises factory produced wall and roof panels. Walls are 2400 mm x 1200 mm x 125 mm thick lightweight interlocking sandwich panels comprising a polyurethane (PU) core encapsulated in two layers of 11 mm thick oriental strand board (OSB). They are clad internally with 15 mm thick fire-resistant gypsum plasterboard and externally with 12 mm thick medium density Nutek board.
The certificate covers the use of the Blast Building System in all areas of South Africa excluding the SCCP area, for the erection of single storey buildings for the uses (SANS 10400: Table 1 of Regulation A (20) (1)) set out below:
· A3 places of instruction
· B2 and B3 moderate and low risk commercial
· H4 dwelling house and related out-building
The Blast Building System foundations consist of conventional concrete surface bed foundation with thickened edge beams and thickening under the internal load bearing walls. Surface bed is power floated to a smooth finish or screed at a later stage G1 office and day clinics
The top layer of Spunsulation 5 Light Roofing Radiant Barrier is manufactured from pigmented ultraviolet light resistant and non-toxic flame retarded non-woven spunbond polypropylene. The layers are laminated by means of homogenous polyolefin based film web to the aluminium foil bottom layer. The membrane has a nominal mass of 174 g/m2 with a thickness of between 0, 29 mm to 0, 31 mm. It is supplied in rolls 30 m long and 1, 5 m wide.
Spunsulation 5 Light Roofing Radiant Barrier is suitable for installation in all tiled-roof buildings with timber roof construction. It was not evaluated for metal roof construction and side-wall cladding
|
